Used Broadcom BCM957414M4143C Single-Port 50 Gb/s QSFP28 Ethernet PCI Express 3.0 x8 OCP 2.0 Mezzanine Card

100% Health

Detail overview

BROADCOM BCM957414M4143C Single-port 50 Gb/s Qsfp28 Ethernet Pci Express 3.0 X8 Ocp 2.0 Mezzanine Card Rohs-compliant.

Overview The BROADCOM BCM957414M4143C Is A Single-port 50 Gb/s, Pci Express 3.0 X8 Mezzanine Card, Designed To The Open Compute Project (ocp) Mezzanine Card 2.0 Design Specification With A Qsfp28 Network Connector As A Type 1 Adapter With The Board Outline Adhering To The Original V0.5 Dimensions. The Adapter Supports Both Qsfp28 Optical Modules And Copper Direct-attach Cables. The Card Uses The BROADCOM Bcm57414 50gbe Mac Controller With An Integrated Single-channel 50gbe Sfi Transceiver.

Features

• Single-port Pluggable Media Interface, Which May Be Equipped With 50 Gb/s Qsfp28 Optical Transceiver Or With Copper Direct-attach Cable
• Fully Compliant With The Sff-8665 Standard
• X8 Pci Express 3.0 Compliant
• Sr-iov With Up To 128 Virtual Functions (vfs)
• Function-level Reset (flr) Support
• Truflow™ Flow Processing Engine
• Virtual Network Termination—vxlan, Nvgre, Geneve, Gre Encap/decap
• Vswitch Acceleration
• Tunnel-aware Stateless Offloads
• Dcb Support: Pfc, Ets, Qcn, Dcbx
• Rdma Over Converged Ethernet (roce)
• Network Controller Sideband Interface (nc-si)
• Smbus 2.0
• Mctp Over Smbus
• Pcie-based Uart And Kcs
• Jumbo Frames Up To 9 Kb
• Advanced Congestion Avoidance
• Multiqueue, Netqueue, And Vmq
• Ipv4 And Ipv6 Offloads
• Tcp, Udp, And Ip Checksum Offloads
• Large Send Offload (lso)
• Large Receive Offload (lro)
• Tcp Segmentation Offload (tso)
• Receive-side Scaling (rss)
• Transmit-side Scaling (tss)
• Vlan Insertion/removal
• Interrupt Coalescing
• Network Boot—pxe, Uefi
• Iscsi Boot
• Wake-on-lan (wol)
• Msi And Msi.x
• Conforms To The Ocp Mezzanine Card 2.0 Design Specification Type 1 Vertical Stack
